Please Carefully Check All Pictures and Part Numbers in the Listing to Make Sure It's the Correct Product you Need

Part Number: 0580254044 044

Application:
For AN10 Inlet AN6 Outlet

Description:
Item Weight: 2.4 Pounds
Dimension
Length: 196mm
Diameter: 60mm
Inlet: M18x1.5 Metric Thread
Outlet: M12x1.5 Metric Thread
Weight: 1,090 g
Technical Data
Operating Voltage: 12V
Min Voltage: 8V
Max Voltage: 18V
Operating Pressure: 75PSI(5.0Bar)
PRV Activation（0-130PSI)
Fow Rate: 200 LPH(53 GPH) under 75PSI(5.0 Bar) & 12V
Flow rate: 300 LPH(80 GPH) under 43 PSI(3.0 bar) &12V
Flow rate: 300 LPH(80 GPH) under 75PSI(5.0Bab) & 13.5V
Current: 15A under 75PSI/12V
High Temperature Reduction: 30 LPH(8 GPH) Operating temperature range: -20 ℃ - 90 ℃（-68 °F-194 °F)
Storage temperature range: -40 ℃- 70 ℃ (-104 °F-158 °F)
Recommended Horsepower Capabilities: up to 750HP for Naturally Aspirated engines & 650HP for Turbo/Supercharged engine
