The Bobcat T770 ranks among the top compact track loaders available today. This powerhouse weighs 10,327 lbs and can handle loads up to 3,475 lbs. The machine has earned its reputation with contractors and construction teams over the past decade. But does it really deserve all the praise?
A $95,800 investment deserves careful evaluation, so we took a closer look at this machine's capabilities. The bobcat t770 specs show an impressive 131-inch maximum lift height and a robust 92 hp turbocharged diesel engine. On top of that, its weight of 4,684 kg creates minimal ground pressure at just 4.2 psi, which lets it work well on different surfaces. The bobcat t770's horsepower tells only part of the story when you evaluate this loader's real-world performance and value.
What Makes the Bobcat T770 Stand Out
Image Source: Bobcat Company
The Bobcat T770 compact track loader leads the pack with raw power, pinpoint accuracy, and adaptability. Contractors love this machine because it hits the sweet spot between capability and performance for their toughest projects.
Key bobcat t770 specs you should know
Here's what makes the T770 a performance beast:
- Rated Operating Capacity (ISO): 3,475 lbs lets you move heavy materials
- Tipping Load: 9,929 lbs keeps you stable with big loads
- Travel Speed: 6.6 mph standard, upgradable to 10.7 mph with two-speed option
- Hydraulic System: 23 gpm standard flow, boosts to 36.6 gpm high-flow option
- Height to Bucket Hinge Pin: 131.4 inches gives you plenty of reach
The vertical lift path design excels at loading trucks, grinders, and hoppers. You can reach up to 11 feet vertically, which opens up many possibilities for high-reach jobs.
How the bobcat t770 weight impacts performance
At 10,515 lbs, the T770's weight plays a crucial role in its capabilities. The track system spreads this weight to create just 4.2 psi ground pressure, letting you work on soft ground without tearing it up.
The machine's weight distribution and minimal ground pressure help you lift heavy loads high while staying stable. Steel imbed tracks, forged steel idlers, and solid-mounted drive motors make the undercarriage system even more reliable.
The T770 turns within 88 inches, so you can move around job sites easily while enjoying its substantial power and weight advantages.
What Owners Love About the Bobcat T770
Operators who've spent time with the Bobcat T770 can't stop talking about how this machine makes their workdays easier and more productive. Their feedback after hundreds of hours behind the controls reveals what makes this powerhouse truly special.
Smooth operation and comfort features
The T770's balanced weight distribution and responsive joystick controls help operators make smooth turns without much drift. The optional automatic ride control stands out as a favorite feature. It cuts down on spills and lets you move faster on rough ground while reducing vibrations in the cab.
The cab's design puts comfort first. An air-ride seat gives operators plenty of room to move, both sideways and front-to-back. Long workdays feel shorter thanks to climate control, Bluetooth radio, and heated seats. Operators stay fresh and alert even during extended shifts.
Versatility across different job sites
The T770's adaptability sets it apart from the competition. This machine handles jobs of all types - from construction sites to farms and everything in between. Its wide range of compatible attachments includes heavy-duty buckets, grapples, augers, mulchers, and pallet forks.
Owners use their T770s for everything from moving seed boxes to mowing brush, grinding stumps, clearing fallen trees with grapple buckets, and forestry mulching. The two-speed travel option hits speeds up to 10.7 mph, which proves invaluable on bigger projects that need lots of movement.
Durability and build quality over time
Long-term owners rave about the T770's toughness. Reinforced lift arms and solid pivot pins keep loads stable, while the frame shrugs off constant bumps and vibrations. The durable undercarriage system features steel imbed tracks and forged steel idlers that stand up to harsh conditions.
Built-in protection features boost this machine's reliability. Cold weather safeguards prevent early wear, smart cooling systems handle tough environments, and thoughtful design protects batteries, hoses, quick couplers, and electronics. These engineering choices explain why T770s deliver years of reliable service to their owners.
What Owners Wish They Knew Before Buying
The Bobcat T770 offers great performance and versatility, but buyers often find several ownership challenges only after they've made their purchase. Here's what actual owners say about their experiences.
Maintenance challenges and hidden costs
The T770's maintenance costs surprise many new owners. A standard 500-hour service costs about $972, and the 1000-hour service costs double that amount. You'll need hydraulic oil changes every 1000 hours, which means 10-20 gallons at $15-20 per gallon.
The maintenance schedule requires daily checks plus services at 50-hour, 250-hour, and 500-hour intervals. While owners can handle some basic maintenance, complex services need dealer attention. Tasks like "changing the fluid in the drive motors, checking the torque of the bolts in the drive motors, and flushing the hydraulic system" add to your long-term costs.
Common issues reported by long-term users
T770 operators consistently point out these problems:
- Track system failures, where tracks come off the rear idler during hard turns
- Drive motor seals break down, and replacement parts can be hard to find
- Bobtach attachment system sometimes lets buckets detach without warning
- Engines start normally but then run at lower RPM
Black smoke under load is another common complaint that points to injector problems. These need professional diagnosis.
Real-life fuel consumption and operating costs
The T770 uses about 2.7 gallons per hour of diesel in typical work conditions. This changes based on the machine's age, upkeep, and how hard you work it. Monthly maintenance runs around $862, which is much higher than skid-steer costs.
Yes, it's true that "track machines can do a lot more work but they have double the operating costs" compared to similar skid loaders. These ground costs can catch you off guard if you're not prepared, despite the machine's capabilities.
Is the Bobcat T770 Still Worth It in 2025?
The Bobcat T770 faces fresh competition from its own product line in the 2025 compact loader market. This 3-year old model costs $88,703, which makes buyers think twice when comparing it with newer options.
Comparison with newer R-series models
Bobcat's R-Series models, the T76 and T86, now compete head-to-head with the T770. The T76 costs slightly less at $88,418 and matches most functions but runs at 74 hp versus the T770's 92 hp. The T86 packs more punch with 105 hp but comes with a hefty price tag of $120,753.
The differences between these models go beyond just horsepower. R-Series models come with:
- One-piece cab design that runs quieter
- Cast-steel lift arm sections built to last longer
- Optional Bluetooth connectivity with 7-inch touchscreen display
- More advanced hydraulic systems
The T770 still shines with its proven track record, easier maintenance, and cheaper replacement parts. Bobcat's medium-sized models like the T770 remain top sellers, showing strong market trust in these machines.
Resale value and long-term investment potential
The T770 holds its value remarkably well in 2025. Used units keep 60-70% of their worth after three years of regular use, which beats many similar machines. The machine's toughness substantially helps maintain this value.
The T770's popularity ensures parts and service support are readily available across the country. This extensive dealer network makes long-term ownership worry-free. The bobcat t770 weight and specs work perfectly for various jobs, which keeps the used market demand steady.
Growing businesses can tap into the potential of Features On Demand performance package with the T770. Users activate new capabilities as their needs grow. The T770 remains a solid choice for contractors who want reliability without paying extra for cutting-edge features, even as newer models hit the market.
Conclusion
The Bobcat T770 really stands out as a serious player in the compact track loader market. A closer look shows this machine still packs a punch with its 92 hp engine, an impressive 3,475 lbs rated operating capacity, and adaptability in a variety of job sites. Without doubt, these specs make it a solid choice for contractors tackling tough projects, even after a decade in production.
Smart buyers should think over both the pros and cons before putting money into this important investment. The upkeep costs can add up - you're looking at $972 for basic 500-hour service, plus the track system tends to need work. The machine's thirst for fuel at 2.7 gallons per hour means running costs are nowhere near what you'd pay with similar skid-steers.
The newer R-Series might come with fancy features like one-piece cab designs and uninterrupted connectivity, but the T770's value shines through its tested reliability, straightforward maintenance, and easy-to-find parts nationwide. The machine holds 60-70% of its value after three years - this is a big deal as it means that contractors can count on strong resale returns.
Your specific project needs and budget will guide the final call. Companies that just need steady performance, flexibility across jobs, and proven reliability will find the Bobcat T770 worth thinking over, even in 2025. The sort of thing I love about this machine is how popular it stays with seasoned operators - that tells you all you need to know about its real-life application, whatever new options hit the market.
